Features

• 4 kinds of DSP karaoke effect selection:
  • Stereo effects
  • Echo effects
  • Two effects mixed with fixed echo return times, with no adjusting
  • Adjust the fix-up effects setup by manufacturer
• CPU Control: High performance 24-bit multi-engine effect process
• Ultra-wide bandwidth from 2Hz to 200kHz for open sound
• Music tone with bass +/-10dB and treble +/-10dB integrated with CPU adjustment
• High-performance 24-bit dual-engine Feedback Destroyer integrated with CPU adjustment
• Two software engines allow independent or coupled functions on left and right channels on lines pre-amplifier
• Single-shot mode automatically searches and attenuates feedback frequencies and locks the filter until manually reset
• Music modulation with 9-step control and adjustable up and down effects for selection
• Music volume lock is used to lock up the super bass integrated with CPU adjustment
• 24 dB/octave, state-variable Linkwitz-Riley filters for precise frequency separation
• Absolutely flat summed amplitude response with zero phase difference
• Separate subwoofer output with independent frequency control
• On/Off switch for super bass
• Dynamic or condenser microphone limiter effectively protects your equipment from overload
• Microphone reverb (echo) time delay and repeat adjusting for parameters between 30ms to 190ms

Specifications

• Source Input: AUX (Manual), CDG(BGM), DVD ( Main )
• Input Function: SAIS (Auto & Manually)
• Power Output: Main - 250 Watts + 250 Watts (8 Ohm), Center – 200 Watts (8 Ohm)
• Microphone Input: 5 (Front x 3, Rear x 2)
• Video Inputs: 3 (RCA jacks)
• Video Outputs: 1 (RCA jacks)
• Audio Inputs: 3 (RCA jacks)
• Audio Outputs: 3 (RCA jacks)
• Music Input Section
• S/N Ratio: >90 dB
• THD: <0.01%
• Input Sensitivity/Impedance: 707mV/47k
• Frequency Response: 20Hz~20kHz, ± 2 dB
• Key Control: 8 steps
• Super Bass (SUB) THD: 0.07% 20Hz ~ 15kHz
• Mic. Input Section
• S/N Ratio: >80 dB
• THD (effect off): 0.04% 50Hz~16kHz
• Frequency Response: 50Hz~20kHz, ± 3 dB
• Input Sensitivity/Impedance: 100mV~500mV/4.7k Ohm
• Equalize
• Low: 100Hz ± 5 dB
• Middle: 1kHz ± 5 dB
• High: 10kHz ± 5 dB
• Standard Power: AC 120V/~60Hz (North America Market) / AC 220V/~50Hz (Asia or Europe Market)
• Dimensions (WxHxD): 17x6x15 (inches)
• Net Weight: 28 Lbs. / 12.7 Kg
• Shipping Weight: 32 Lbs. / 14.5 Kg
